Search found 159 matches

by lowact
Tue Nov 12, 2019 7:25 am
Forum: Series 3
Topic: Head removal tool
Replies: 4
Views: 464
Australia

Re: Head removal tool

Reporting that this design, with nuts under the plate instead of threaded holes in the plate, is not suitable for preHE. Following photo, tappet block on the right is HE, flange has cut-outs above the head bolt locations that provide clearance for the nuts. On the left is my E-type tappet block, no ...
by lowact
Tue Nov 12, 2019 7:04 am
Forum: Series 3
Topic: Acrid smoke and low vacuum
Replies: 29
Views: 3049
Australia

Re: Acrid smoke and low vacuum

Timing chain tensioner good? Thought it was, but i was wrong. Couldn't tell by looking but as soon as I tried to ease off a bit of tension it fell apart. No flex there at all, Should have known, 50 yo plastic ... https://i.postimg.cc/CKDYtNB8/20191112-170445.jpg Time for a beer while I ponder my ne...
by lowact
Sun Nov 10, 2019 1:00 pm
Forum: Series 3
Topic: Acrid smoke and low vacuum
Replies: 29
Views: 3049
Australia

Re: Acrid smoke and low vacuum

Not yet, but I must be getting close ... https://i.postimg.cc/KYZvnr0J/20191110-215641.jpg The clatter returned (so wasn't just the air pump) and became continuous, no longer stopping when the engine had warmed up. Good reason to start the HE upgrade. I'm suspecting the acrid smoke was due to old va...
by lowact
Thu Nov 07, 2019 1:30 am
Forum: Series 3
Topic: XJ12 Engine
Replies: 9
Views: 594
Australia

Re: XJ12 Engine

I believe HE's first appeared in 1979. It would be useful to understand why change was made, why the engine numbers don’t match? You have preHE heads and, according to my interpretation of engine no’s, a HE engine block. Less issues if I were wrong about this.To double-check the engine block, compar...
by lowact
Mon Nov 04, 2019 12:13 am
Forum: Series 3
Topic: Problem with horn on Moto Lita steering wheel
Replies: 4
Views: 174
Australia

Re: Problem with horn on Moto Lita steering wheel

I assume "solder" means to braize using a gas torch. Alternatively drill and tap for a screw into the end of the rod that can be adjusted to length and held by a lock nut?
by lowact
Fri Nov 01, 2019 11:30 pm
Forum: Series 3
Topic: XJ12 Engine
Replies: 9
Views: 594
Australia

Re: XJ12 Engine

Nah, if not HE is not 11.5. And if carburetors not S3 either? Engine number, are you sure that the 1st numeral after the P is a 7?. What car is it in? If E-type, what is the engine number on the plate on the firewall? One explanation, if for some reason the e-type block had to be replaced, and all t...
by lowact
Fri Nov 01, 2019 11:04 pm
Forum: Series 3
Topic: High Beam Headache
Replies: 16
Views: 795
Australia

Re: High Beam Headache

Seems to me you have proven that the problem is exactly as Ole predicted, broken pin/hole connections in this plug. Seems PO work around was to reroute the headlight supply from pin 2 or 3 to the centre pin 4 – via purple/yellow, red/yellow wires on the back of the socket. If this is correct u shoul...
by lowact
Fri Nov 01, 2019 12:17 pm
Forum: Series 3
Topic: High Beam Headache
Replies: 16
Views: 795
Australia

Re: High Beam Headache

I’m calling the connector with the holes the plug and the one with the pins the socket. My car is ’72 us spec, I imported it, should (?) be the same as yours. My plug is not missing any metal inserts, each hole on the plug (and pin on the socket) is labelled with a number, 1-8. Holes 1-4 are slightl...
by lowact
Fri Nov 01, 2019 6:00 am
Forum: Series 3
Topic: Has Anyone Fitted the Tremac 5 Speed ?
Replies: 21
Views: 665
Australia

Re: Has Anyone Fitted the Tremac 5 Speed ?

Here is my spreadsheet for comparing drive-train configurations. https://1drv.ms/x/s!AiSPBKa26IcchM5oxMeM7zron2FXnQ?e=zze30n Inputs include choice (from drop-down lists) of engine (torque curve), gearbox (Jaguar, T5, Getrag), diff ratio. Output is revs, maximum torque and minimum torque versus road ...
by lowact
Wed Oct 30, 2019 6:57 am
Forum: Series 3
Topic: High Beam Headache
Replies: 16
Views: 795
Australia

Re: High Beam Headache

When headlights are on, side lights would also be on, so not much proved yet? The centre pin is #4? According to my wiring diag: 2 = high beam 3 = low beam 5 = side lamps 7 = RH flasher 8 = LH flasher The others don’t feature. The wiring diag suggests that the supply to the rear sidelights is from t...
by lowact
Wed Oct 30, 2019 3:42 am
Forum: Series 3
Topic: Engine stand reservations
Replies: 7
Views: 379
Australia

Re: Engine stand reservations

Ok, thx, based on this I've just gone out and pulled a lot more of the load back onto the hoist (crank pulley) pending next step... I went for the highest and lowest bolts, incl. the starter motor bolt, so that the effective moment arm would be longest, so the tensile load on bolt holes would be the...
by lowact
Wed Oct 30, 2019 2:39 am
Forum: Series 3
Topic: Engine stand reservations
Replies: 7
Views: 379
Australia

Re: Engine stand reservations

Thx peoples, in the end I used the two uppermost and two lowermost bell-housing bolt holes, I.e.: https://i.postimg.cc/dtqNSS35/20191030-115710.jpg My main concerns are about the stresses on the engine block bolt holes. The two lower holes will be in compression while the two upper holes (each 15 mm...
by lowact
Sun Oct 27, 2019 8:15 am
Forum: Series 3
Topic: Engine stand reservations
Replies: 7
Views: 379
Australia

Engine stand reservations

Getting ready to support my 350kg engine on a shiny new 900 kg engine stand. https://i.postimg.cc/mDzdMqXX/20191027-181211.jpg Lots of people must have done this before, still I’m not comfortable. Do we know of any problems, issues? Do we know which bell-housing bolt-holes are best to use? Two on to...
by lowact
Sun Oct 27, 2019 7:51 am
Forum: Series 3
Topic: S3 4 Speed Auto Gearbox
Replies: 14
Views: 4050
Australia

Re: S3 4 Speed Auto Gearbox

Um… clutch reservoir, hydraulic lines, hydraulic slave cylinder, hydraulic master cylinder, new pedal box with clutch pedal & master cylinder mounting, flywheel with pressure plate, clutch cover, clutch plate, release bearing, clutch fork, bell housing, xj6 gearbox modified for slave cylinder mounti...
by lowact
Wed Oct 23, 2019 11:53 am
Forum: Series 3
Topic: XJ12 Engine
Replies: 9
Views: 594
Australia

Re: XJ12 Engine

I suspect not. Yr engine, 7P76**LA, would be much later than '79. Later than mine (7P55**HB) which is '86. It is series 3 HE? HE engines, all the spark plugs angle inwards and are 16 mm. Pre-HE, the front 6 plugs angle forward, the rear 6 angle backwards and are 19 mm. High comp. is a defining chara...
by lowact
Wed Oct 23, 2019 12:06 am
Forum: Series 3
Topic: High Beam Headache
Replies: 16
Views: 795
Australia

Re: High Beam Headache

Original did not have headlight relay. Pwr to the headlights AND the H/B indictor (blue) light is from the fuses after the dip switch. So it can't be the dip switch?
by lowact
Tue Oct 22, 2019 10:04 pm
Forum: Series 3
Topic: XJ12 Engine
Replies: 9
Views: 594
Australia

Re: XJ12 Engine

From jag-lovers SOHC V-12 Engines 7Sxxxxx 5.3 Liter E-type 7P1001 5.3 Liter XJ12/Daimler Double SIx Series 1 w/carburetters 7P4000 5.3 Liter XJ12 & D6 Series 2 w/carburetters 7P25001 5.3 Liter XJ12 & D6 Series 2 w/fuel injection 7P42300 5.3 Liter XJ12 Series 3 Pre-HE (suffix ? = 9:1, suffix HA = 10:...
by lowact
Thu Oct 17, 2019 10:31 am
Forum: Series 3
Topic: Crankshaft Pulley
Replies: 10
Views: 617
Australia

Re: Crankshaft Pulley

Hello Michel. My interpretation is that only an E-type pulley will work, part C32528. I don’t believe it was used on any other car, I interpret that all XJ12, XJS use the larger one, part C37892. Because of the oil filter pipe, only E-types have this (oil filter at the front). You may need to get a ...
by lowact
Wed Oct 16, 2019 12:56 am
Forum: Series 3
Topic: Recalibrating the Speedo
Replies: 5
Views: 394
Australia

Re: Recalibrating the Speedo

Here are instructions for recalibrating Smiths speedo and odometer ...
https://1drv.ms/b/s!AiSPBKa26IcchM5cQkn ... A?e=fQijSw
by lowact
Wed Oct 16, 2019 12:27 am
Forum: Series 3
Topic: Crankshaft Pulley
Replies: 10
Views: 617
Australia

Re: Crankshaft Pulley

Hello Michel. Paul’s HE XJ12 is probably same as mine (S3, 1886). It has the larger (15 cm dia.) pulleys that are all the same size, no use to you. What vintage is your XJS engine? I assume you have the earlier water pump and oil filter arrangement? On the E-type the steering pump belt runs through ...
