Search found 149 matches

by angelw
Tue Feb 13, 2018 4:54 am
Forum: Series 2
Topic: Water thrower
Replies: 9
Views: 908
Australia

Re: Water thrower

Hello Rich, Given your current predicament, I can't say I'd describe the help as being invaluable. On S3 and other late Hub Carriers, the lugs shown enclosed in Red in the following picture (Hub 1) are included. For these hubs I have a fixture for the press that supports the hub carrier on these poi...
by angelw
Tue Feb 13, 2018 3:45 am
Forum: Series 3
Topic: 4 Speed Manual OD Gearbox Identification
Replies: 21
Views: 1793
Australia

Re: 4 Speed Manual OD Gearbox Identification

Hello Steve, I have the benefit of a well equipped CNC machine shop, but the same operations can be done on a manual milling machine. 1. Spot Face dia 3/4" (19.05mm) at the location of where the mounting points should be. You can't go very deep with these due to the relatively thin wall thickness of...
by angelw
Mon Feb 12, 2018 8:55 pm
Forum: Series 3
Topic: 4 Speed Manual OD Gearbox Identification
Replies: 21
Views: 1793
Australia

Re: 4 Speed Manual OD Gearbox Identification

Hello Steve, Yes, this a KFN box and has the Slave Cylinder Mounting on the side of the box, blanked off with the two bolts shown. Its my understanding that all KF boxes have the Gearbox mount for the Slave Cylinder; at least all that I've handled have. The "N" in the Prefix simply refers to the Gea...
by angelw
Mon Feb 12, 2018 8:06 pm
Forum: Series 3
Topic: 4 Speed Manual OD Gearbox Identification
Replies: 21
Views: 1793
Australia

Re: 4 Speed Manual OD Gearbox Identification

Hello Steve, The attached picture below shows an authentic Overdrive Gearbox sourced from an XJ6, complete with the Slave Cylinder Mounting on the side of the Gearbox and on the Bell Housing. https://s9.postimg.cc/l9roplyv3/XJ6_Gearbox1.jpg MK10's were available with a 4 speed synchromesh box, but d...
by angelw
Sun Feb 11, 2018 7:07 am
Forum: Series 3
Topic: 4 Speed Manual OD Gearbox Identification
Replies: 21
Views: 1793
Australia

Re: 4 Speed Manual OD Gearbox Identification

Malcolm Wrote: Bill, As you have done the conversion many times is there a difference in the transmission tunnel width? Is is tighter after the pedal box is installed and is there room to rest your left foot or does it have to hover over the clutch pedal? Hello Malcolm, The pedal box is the same uni...
by angelw
Sat Feb 10, 2018 9:03 pm
Forum: Series 3
Topic: 4 Speed Manual OD Gearbox Identification
Replies: 21
Views: 1793
Australia

Re: 4 Speed Manual OD Gearbox Identification

Hello Malky, Unless you plan on always driving the car sedately, Its advisable to upgrade the overdrive to competition spec - springs, pump. UDC/ clutch etc. Overdrive Spares can do this work for around £500.00 plus carriage plus VAT. The link to them follows: http://www.odspares.com/phdi/p1.nsf/......
by angelw
Fri Feb 09, 2018 1:57 am
Forum: Series 2
Topic: Water thrower
Replies: 9
Views: 908
Australia

Re: Water thrower

Rich Wrote Just a quick question regarding the rear hub water throwers. In changing the hub bearings, the original water thrower had to be sacrificed. Hello Rich, Why did the water throwers have to be sacrificed? We replace rear hub bearings on a regular basis and have done so for years, without an...
by angelw
Wed Feb 07, 2018 10:10 pm
Forum: Series 3
Topic: Charging issue on my series 3
Replies: 33
Views: 2111
Australia

Re: Charging issue on my series 3

Djerome60 Wrote: actually i just remonved the negative plug as i have 3 single connectors Hello Djerome60, There are three terminals on the Voltage Regulator, Positive, Negative and Field. With 3 separate connectors, the wire from the ignition warning light (Brown/Black changing to Brown/Red) conne...
by angelw
Sun Feb 04, 2018 11:25 am
Forum: Technical
Topic: Output shaft bearings
Replies: 7
Views: 445
Australia

Re: Output shaft bearings

Hello Steve, The original output bearings you refer to are double row, angular contact, ball bearing type, where the inner race is made in two halves with a slight gap between the inner ends (designed pre-load clearance) when the bearing is assembled and held together with just hand pressure. The In...
by angelw
Wed Jan 31, 2018 12:51 pm
Forum: Series 2
Topic: Cost of respray
Replies: 32
Views: 3737
Australia

Re: Cost of respray

Hello All, One of the most, if not the most important component of spray painting is air quality and dryness. No amount of quality material or painting skill will improve the quality of the air delivering the paint to the panel. Typically, most home, or amateur spray painting set ups include a simpl...
by angelw
Fri Jan 26, 2018 7:19 am
Forum: Series 3
Topic: Heritage Throttle body injection
Replies: 32
Views: 2693
Australia

Re: Heritage Throttle body injection

In terms of balance, that looks to be quite an amount of material removed at a large diameter for the main index mark. Did you have the flywheel balanced after the index marks were machined?

Regards,

Bill
by angelw
Fri Jan 19, 2018 6:43 am
Forum: Technical
Topic: Which side is what ??
Replies: 1
Views: 404
Australia

Re: Which side is what ??

Hello Darren,
I can't take a measurement until tomorrow, but typically the folded flange, as shown enclosed in the attached picture, goes towards the front. Accordingly, Left and Right will be as indicated in the picture below.


Regards,

Bill
by angelw
Fri Jan 19, 2018 6:11 am
Forum: Technical
Topic: Clutch knocking noise
Replies: 74
Views: 6927
Australia

Re: Clutch knocking noise

All the gears are spinning (free wheeling) all of the time when not engaged and with the clutch engaged. Disregarding the Lay-shaft cluster gears, the Reverse Idler spins the 2nd quickest at approximately 100 revs per 1000 engine revs less than third gear (which spins the quickest). Fourth Gear is e...
by angelw
Thu Jan 18, 2018 12:36 pm
Forum: Technical
Topic: Hub oil seals
Replies: 2
Views: 326
Australia

Re: Hub oil seals

Hello Steve,
I use both and each work fine once installed. A bit more care is required for the Aftermarket Unit, as they are easily distorted when installing. I have an arbor that spreads the load over nearly the whole surface area of the seal's face when pressing it into position.

Regard,

Bill
by angelw
Thu Jan 18, 2018 12:26 pm
Forum: Technical
Topic: Clutch knocking noise
Replies: 74
Views: 6927
Australia

Re: Clutch knocking noise

Brian Wrote Ken’s initial thoughts are indeed a broken tooth as you suggested Hugo. I guess I will know for sure later in the week when he gets it apart. Hello Brian, If broken tooth it would be the First Motion/Lays-shaft cluster, or Lay-shaft Cluster/ Reverse Idler Gear combinations. Having read y...
by angelw
Sun Jan 14, 2018 10:23 am
Forum: Technical
Topic: Gear box locked up
Replies: 10
Views: 1566
Australia

Re: Gear box locked up

Christopher Wrote: I'm not sure that he did . he said as I understood it that the gearbox was stuck in reverse as denoted by the input and outputs rotating in contrary motion. If he had two gears selected simultaneously, the gearbox would have locked up completely Hello Christopher, You're correct. ...
by angelw
Sat Jan 13, 2018 6:56 pm
Forum: Technical
Topic: Gear box locked up
Replies: 10
Views: 1566
Australia

Re: Gear box locked up

Tony Wrote: Removed the cover, when I moved the reverse fork the gears freed up, phew. Need a gasket, then job done. Hello Tony, You have fixed the issue but perhaps not the cause. There are two ball bearings and a roller separating them, at the front of the Top Cover (inside); their function is to ...
by angelw
Thu Jan 11, 2018 7:10 pm
Forum: Series 3
Topic: s3 auto to manual conversion.
Replies: 7
Views: 1013
Australia

Re: s3 auto to manual conversion.

Rob Wrote: Has anyone done this conversion? I have an option on a standard gearbox or an overdrive box which appears to be dimensionally identical ,any thoughts or ideas,or spares ie. bellhousing,flywheel ,clutch pedal? Hello Rob, By Overdrive Box, do you mean a Jaguar 4 speed with a Type A Laycock ...
by angelw
Fri Jan 05, 2018 10:53 am
Forum: Technical
Topic: Rear Inner Fulcrum Shaft Bearing Tubes - Material ?
Replies: 26
Views: 3062
Australia

Re: Rear Inner Fulcrum Shaft Bearing Tubes - Material ?

John Wrote: The rear subframe already has eccentric bushes and they are held in place by welds. The bushes that the inner fulcrum shaft passes through on the frame itself are eccentric, no doubt to allow manufacturing tolerances to be zeroed out on a jig before welding them in place. Remove the weld...
by angelw
Tue Jan 02, 2018 11:16 am
Forum: General
Topic: Rust Removal using Phosphoric Acid
Replies: 76
Views: 9941
Australia

Re: Rust Removal using Phosphoric Acid

John wrote: "POR15" is not a rust convertor, just a high quality primer paint that prevents further moisture and oxygen reaching the metal it's applied to. It does imply on the tin that you can spray it; whether that's an effective way to apply a very expensive product depends on what you're trying ...
