Clutch fluid gone.

Talk about the E-Type Series 2

Topic author
AnD3rew
Posts: 45
Joined: Sun Jul 30, 2017 10:31 pm
Australia

#1 Clutch fluid gone.

Post by AnD3rew » Sun May 19, 2019 8:06 am

I have to admit to having been a negligent parent and having never consciously checked the clutch fluid level on my Series 2. Last week the clutch started feeling a bit soft. I checked the fluid and it was basically gone, just a bit of sludge in the bottom of the reservoir. I have owned if for two years and no idea when it was last replaced or even topped up (lesson learnt). I have cleaned out the reservoir and put new fluid in and bled and all is working fine.

The question is, where did the fluid go? I can’t see any signs of leaked inside the footwell, inside the engine bay around the master cylinder or around the slave.

I don’t think the fluid just evaporated on its own so there must be a source of the leak but I can’t see it.
Sydney Australia

Current
Jaguar Red Series 2 2+2 XKE 1969
Jaguar Italian Racing Red F-Type S 2014
Jaguar XJ6 Vanden Plas dark green 1985
Jaguar XJS V12 Silver 1987


Previous of interest
Jaguar XJ6 Sovereign series 3
MGA 1959

Link:
BBcode:
HTML:
Hide post links
Show post links

User avatar

mgcjag
Moderator
Posts: 4244
Joined: Fri Jul 09, 2010 6:15 pm
Location: Ludlow Shropshire
Great Britain

#2 Re: Clutch fluid gone.

Post by mgcjag » Sun May 19, 2019 8:12 am

Hi...whats your name ..please try to put it with your car model in the signature area.......fluid loss...where could it have gone.......either leaked from seal behind pedal and run down behind and under carpets......or into the resivac tank...or into the servo...there are good detailed diagrams of the brake system showing fluid and vacume systems that will help you understand how it all works.....or on here if you look at similat topics below.....Steve
Steve
1969 S2 2+2 & Building a C type replica

Link:
BBcode:
HTML:
Hide post links
Show post links


Topic author
AnD3rew
Posts: 45
Joined: Sun Jul 30, 2017 10:31 pm
Australia

#3 Re: Clutch fluid gone.

Post by AnD3rew » Sun May 19, 2019 8:17 am

mgcjag wrote:
Sun May 19, 2019 8:12 am
Hi...whats your name ..please try to put it with your car model in the signature area.......fluid loss...where could it have gone.......either leaked from seal behind pedal and run down behind and under carpets......or into the resivac tank...or into the servo...there are good detailed diagrams of the brake system showing fluid and vacume systems that will help you understand how it all works.....or on here if you look at similat topics below.....Steve
Name is Andrew, thought it was obvious from my user name, but can put it in sig, Thanks I have seen the diagrams, I have looked under the carpets inside there is no sign of leaks, was hoping someone had experienced similar to suggest where to start. I’m not sure I know what bit you are talking about when you say resided tank, this is clutch not brake, I can’t see what you mean by resivac tank?
Last edited by AnD3rew on Sun May 19, 2019 8:25 am, edited 1 time in total.
Sydney Australia

Current
Jaguar Red Series 2 2+2 XKE 1969
Jaguar Italian Racing Red F-Type S 2014
Jaguar XJ6 Vanden Plas dark green 1985
Jaguar XJS V12 Silver 1987


Previous of interest
Jaguar XJ6 Sovereign series 3
MGA 1959

Link:
BBcode:
HTML:
Hide post links
Show post links

User avatar

mgcjag
Moderator
Posts: 4244
Joined: Fri Jul 09, 2010 6:15 pm
Location: Ludlow Shropshire
Great Britain

#4 Re: Clutch fluid gone.

Post by mgcjag » Sun May 19, 2019 8:29 am

Hi Andrew.....sorry...yes my mistake........just read it as fluid gone........as saw you online so wanted to try to help.....clutch is far simpler......nowhere the fluid could hide.......it can seep through tbe rubber hoses....but to loose it all i dont know.....Steve
Steve
1969 S2 2+2 & Building a C type replica

Link:
BBcode:
HTML:
Hide post links
Show post links


Topic author
AnD3rew
Posts: 45
Joined: Sun Jul 30, 2017 10:31 pm
Australia

#5 Re: Clutch fluid gone.

Post by AnD3rew » Sun May 19, 2019 9:35 am

mgcjag wrote:
Sun May 19, 2019 8:29 am
Hi Andrew.....sorry...yes my mistake........just read it as fluid gone........as saw you online so wanted to try to help.....clutch is far simpler......nowhere the fluid could hide.......it can seep through tbe rubber hoses....but to loose it all i dont know.....Steve
Thanks Steve, looks like still a mystery. I guess just need to keep my eyes on it for now.
Sydney Australia

Current
Jaguar Red Series 2 2+2 XKE 1969
Jaguar Italian Racing Red F-Type S 2014
Jaguar XJ6 Vanden Plas dark green 1985
Jaguar XJS V12 Silver 1987


Previous of interest
Jaguar XJ6 Sovereign series 3
MGA 1959

Link:
BBcode:
HTML:
Hide post links
Show post links

User avatar

abowie
Posts: 2141
Joined: Wed Sep 07, 2011 9:15 pm
Location: Australia
Contact:
Australia

#6 Re: Clutch fluid gone.

Post by abowie » Sun May 19, 2019 10:13 am

That's what I'd do. If it's not in the footwell or soaking the trim above it it's leaked out somewhere else.
Andrew.
881824, 1E21538. 889457..oops
http://www.projectetype.com/index.php/the-blog.html
Adelaide, Australia

Link:
BBcode:
HTML:
Hide post links
Show post links


tim wood
Posts: 535
Joined: Fri Nov 20, 2009 6:52 pm
Location: Leighton Buzzard UK
Great Britain

#7 Re: Clutch fluid gone.

Post by tim wood » Sun May 19, 2019 10:53 am

Of course it could simply be that the clutch slave has failed. Hardly an unknown problem.
Quick look and a grope around should I indicate.

Tim
Series 1 FHC purchased 40 years ago when I was young. Sold
Series 1 2+2 when the kids were small now sold
Series 1.5 OTS in opalescent maroon, Californian car. My retirement present.

Link:
BBcode:
HTML:
Hide post links
Show post links


Topic author
AnD3rew
Posts: 45
Joined: Sun Jul 30, 2017 10:31 pm
Australia

#8 Re: Clutch fluid gone.

Post by AnD3rew » Sun May 19, 2019 11:09 am

tim wood wrote:
Sun May 19, 2019 10:53 am
Of course it could simply be that the clutch slave has failed. Hardly an unknown problem.
Quick look and a grope around should I indicate.

Tim
I had a good look, the body of the slave has a bit of surface rust, but the cap etc all looks intact and I can’t see any moisture or leakage. Now I have filled the fluid and bled the clutch is working fine.
